Electrocerradura VDS 12V with push button for swing door

Electrocerradura VDS 167 / E 12V with push-button for swing doors

The electrocerradura VDS 167 / and, model ELC, it is an electric lock 12v For swing and folding doors, indicated to increase the safety of automation closure.

It can work by electric boost from the control plant or through the integrated pushbutton, as long as this function is enabled with the key.

Its design allows installation right or left, so it can be adapted to different door configurations.

It is supplied with 3 keys and is indicated both for residential and industrial facilities.

12V reversible electronization

✓ Reference VDS 167 / and.

✓ ELC.

✓ 12v.

✓ Installation right / left.

✓ Integrated pushbutton.

✓ Includes 3 keys.

✓ Complete central electro-cornence for swing or folding doors.

✓ Drive by electric boost.

✓ Possibility of opening through button.

✓ The button can be enabled or disabled by the key.

✓ Fit for installations right or left.

✓ Suitable for systems Porter, video door entry and access control.

✓ indicated for use residential and industrial.

✓ Recommended for hinged doors up 300 kg.

The electrolyberra can be operated by a electric boost From the central, doorman, video door entry or access control system.

The Integrated push button When this function is enabled by the key.

The button can be deactivated by turning the key, allowing you to limit the opening to electrical control or by key.

VDS recommends leaving a Minimum separation of approximately 5 mm Between the body of the lock and the stop element.

The loading of the spring can be adjusted by the internal hexagonal nut according to the weight of the door and its closing speed.

To obtain correct operation, the wiring must be properly dimensioned depending on the distance between the center and the lock.

Important about feeding

VDS Indicates using a voltage of approximately 9 - 12VDC and that the voltage measured directly in the terminals of the electroncloth during the impulse should not be less than 8v.

The Electrical impulse should not exceed 8 seconds.

Maintenance

To lubricate the mechanism, VDS recommends Powder graphite lubricant.

Electronement can be used with automation power plants that have Suitable output for 12V electroning.

It can also be integrated with systems of Electronic goalkeeper, video door entry and access control.

It can be used as an alternative to other similar application electrocker, as long as they are previously checked Tension, dimensions, mounting direction and fixing system.

■ 1 × Electronement VDS ELC REF. 167 / and.

■ 3 × keys.
