Motor seccional Brushless MATIKGATE LIFE para Puertas Residenciales hasta 17m²
Referencia: LIFT
€233.00
IVA excluido
281,93 €
IVA incluido
Brushless MATIKGATE Roof Engine LIFE of 24Vdc for residential sectional doors with iron guide with strap.
Targeted to the residential segment, LIFT is a 24V DC belt brushless engine with power up to 200W to automate doors to 17m2. Developed for intensive use, it stands out for its high quality materials and its modern and distinctive design, ensuring silence, reliability and reduced maintenance. Allows the connection to the MATIKGATE APP (optional).
We ship your order within 24/72 hours
Secure payment: Card, Bank transfer, Bizum
Fast shipping from Spain
Sectional motor Brushless MATIKGATE LIFE
Brushless MATIKGATE Roof Engine LIFE of 24Vdc for residential sectional doors with iron guide with strap.
Targeted to the residential segment, LIFT is a 24V DC belt brushless engine with power up to 200W to automate doors to 17m2. Developed for intensive use, it stands out for its high quality materials and its modern and distinctive design, ensuring silence, reliability and reduced maintenance. Allows the connection to the MATIKGATE APP (optional).
Technical characteristics
| Model | 800N | 1200N | 1800N |
| Food | 230Vac | 230Vac | 230Vac |
| Motor | 24V | 24V | 24V |
| Power | 80W | 120W | 180W |
| Force | 800N | 1200N | 1800N |
| Frequency of use | Intensive | Intensive | Intensive |
| Speed | 18cm/s | 18cm/s | 18cm/s |
| Operating temperature | -20oC +50oC | -20oC +50oC | -20oC +50oC |
| Protection | IP20 | IP20 | IP20 |
| Max dimensions. Door | 12m2 | 14m2 | 17m2 |
KIT Composition:
- 1 Brushless motor
- 1 Guide to belt
- 2 Emissors COPPER RollingCode 433.92 MHz
- 1 Pair of photocells F180
- 1 BLINK flashlight
Measures MATIKGATE LIFT
Product Details
LIFT
Data sheet
- Type of engine
- Electromechanical 24V
- Force (N)
- 1,000N
- Force (N)
- From 1,200N
- Maximum door area (m2)
- from 10m² to 13m²
- Maximum door area (m2)
- from 14m² to 17m²
Specific References
Brushless MATIKGATE Roof Engine LIFE of 24Vdc for residential sectional doors with iron guide with strap.
Targeted to the residential segment, LIFT is a 24V DC belt brushless engine with power up to 200W to automate doors to 17m2. Developed for intensive use, it stands out for its high quality materials and its modern and distinctive design, ensuring silence, reliability and reduced maintenance. Allows the connection to the MATIKGATE APP (optional).
