FG CLEMSA
€102.00
VAT excluded

123,42 €

Tax incl.

Machinery for making pulp of fibrous cellulosic material Clemsa, to detect vehicles (cars or motorcycles) when that vehicle passes over the door, it reverses the maneuver just as if we were passing in front of a photocell. A magnetic loop is also usually installed to prevent an owner from opening the door to enter on foot, therefore the door would only open if the magnetic loop detects a vehicle in the area where the winding is installed (usually in the buried ground).

MODEL FG CLEMSA



We ship your order within 24/72 hours



Secure payment: Card, Bank transfer, Bizum



Fast shipping from Spain Except bulky



Detector de masas metálicas Clemsa, para detectar vehículos (automóviles o motos) cuando dicho vehículo pasa por encima del la puerta, reinvierte la maniobra al igual que si pasáramos por delante de una fotocélula. También se suele instalarse un lazo magnética para evitar que un propietario abra la puerta para entrar de forma peatonal, por lo tanto la puerta solo abriría si el lazo magnético detecta un vehículo en la zona donde se instala el bobinado (normalmente en el suelo enterrado).

MODELOS DISPONIBLES

  • FG 10: Detector monocanal 230 Vac
  • FG 20: Detector bicanal 230 Vac
  • FG 1: Detector monocanal 24 Vac
  • FG 2: Detector bicanal 24 Vac

CARACTERÍSTICAS

  • Gestión de una o dos espiras con alimentación 230 Vac y 24 Vac
  • 4 niveles de sensibilidad independientes.
  • Actualización continua de la frecuencia de trabajo.
  • Relé de presencia NA/NC y relé impulsivo.
  • Autocalibración.
  • Señalización en caso de interrupción o cortocircuito de la espira.
  • Lazo inductivo
  • Frecuencia presencia / de reacción: 1 minuto a infinito / 25 ms
  • Frecuencia máxima / Consumo: 48 a 62 Hz / 2,5 W
  • Grado de protección: IP40 / -30ºC a +55ºC
  • Indicadores Led rojo/verde
  • Dimensiones: 77 x 40 x 75 mm

MEDIDAS
