Motorline MR5 | 433MHz EXTERIOR 12 / 24V BICANAL RECEIVER
MR5
€35.00
VAT excluded
42,35 €
Tax incl.
Bistable and monostable Bicyanal receiver; With a box included; Capacity for 500 codes Rolling Code.
The Bicanal Radio MR5 receiver allows remote control of electrical and electronic equipment with one or more radio controls.
We ship your order within 24/72 hours
Secure payment: Card, Bank transfer, Bizum
Fast shipping from Spain Except bulky
Motorline MR5 | Outdoor Bicyanal Receiver 12 / 24V
Bistable and monostable Bicyanal receiver; With a box included; Capacity for 500 codes Rolling Code.
The Bicanal Radio MR5 receiver allows remote control of electrical and electronic equipment with one or more radio controls.
Type of operation of the relays:
The receiver is capable of managing the two channels individually and, in addition, it also allows different operating modes:
- Channel CH1: submit monostable functioning, with the possibility of activating distance programming.
- CH2 channel: Through the SW1 switch selection, it is possible to select the following operating modes for the CH2 channel (PGM mode in the distance, and the monostable operation)
Technical characteristics Motorline Mr
| Description | Value |
|---|---|
| Frequency | 433,92 MHz |
| Feed | 12-24 VAC / VDC |
| Max consumption | 5 W |
| Code type | 12/18/32 Bit or Rolling Code |
| Memorization of TX codes (CH1 + CH2) | 500 max. |
| Relay | 30V DC 1A |
| Operating temperature | -25 ° C A + 55 ° C |
| Dimensions | 53 × 82 × 40 mm |
| Scope in free space | 50-100 m |
| Degree | MR5 - IP42 / MR6 - IP54 |
Manual
