Electromechanical barrier Aprimatic PARK at 24V intensive use with mast from 3 to 6 meters with built-in maneuver box.

The automatic PARK barrier is designed for the control of vehicles in confined spaces with heavy traffic such as a residential area or residential areas. Automatic barrier exterior steel with cataphoresis treatment painted polyester. 24 V motor with encoder and programmable control panel with end-of-course deceleration functions and obstacle detection system. the automatic barrier incorporates external unlocking for manual manoeuvring in case of power failure. Optionally an oval arm with LED lighting up to 5 m can be installed.

• Automatic electromechanical barrier of 24 Vdc with encoder.
• Use in heavy traffic.
• Locked outdoor unlock.
• Torque control with reversal in case of obstacle.
• Control panel with deceleration at the end of the race.
• 3, 4, 5 and 6 m arms.
• Aperture from 2.5 s to 9 s. Up to 1000 cycles/day
• Easy left/right hand switch
• PARK 30 has race terminals, necessary for use in Parking.

MATTILATE TIPES

• KTP30RD: round arm D80 mm, L=3 m. Open in 2.5 seconds . Micro-switches at the end of the race.
• KTP30OV: Oval arm H65 mm, L=3 m. Open in 2.5 seconds . Micro-switches at the end of the race.
• KTP30OVLED: Oval arm H65 mm with LEDs, L=3 m. Open in 2.5 seconds . Micro-switches at the end of the race.
• KTP40RD: Round arm D80 mm, L=4 m. Open in 3.5 seconds .
• KTP40OV: Oval arm H65 mm, L=4 m. Open in 3.5 seconds .
• KTP40OVLED: Oval arm H65 mm with LEDs, L=4 m. Open in 3.5 seconds .
• KTP50RD: round arm D80 mm, L=5 m. Opening in 6.0s.
• KTP50OV: Oval arm H65 mm, L=5 m. Opening in 6.0s.
• KTP50OVLED: Oval arm H65 mm with LEDs, L=5 m. Opening in 6.0s.
• KTP60RD: Round arm D80 mm, L=6 m (4+2). Opening in 9.0s.

NotesThe following: all barriers come without receiver and without controls, so if you need them you can add them additionally from the product accessories

TECHNICAL CHARACTERISTICS

ACTION

MANUAL

Technical data sheet Aprimatic PARK

Instruction manual Aprimatic PARK

Instruction manual Aprimatic Traffic park

APRIMATIC PARK
