■ Soft stop function on opening and closing.
■ Force regulator.
■ Locking type can be automatic by means of an independent memory or manual rest time regulator.
■ Independent opening and closing time regulator.
■ Opening and closing end connections.
■ 12 V AC/DC electric lock activation output with the possibility of a reversal stroke, garage light contact, flashing light, alternating button and pedestrian button.
■ It has two independent safety inputs, one for the photocell which acts when the door is closed and another which can be connected to a photocell or to a pneumatic band with resistive contact. The latter can be selected by means of a micro-switch. With the switch on OFF the safety acts only on opening, stopping the door, or for the door and inverts for 1 second both on opening and on closing.
■ The table has an output for testing photocells. It can be used in the case of mounting test input photocells or emitter/receiver photocells.

■ An external receiver card can be added in addition (the different frequency compatible cards can be found below)

MANULES

Instruction manual AERF DUAL 2H4
