MC75
€39.00
VAT excluded

47,19 €

Tax incl.

Electronic switchboard Motorline MC75 for indoor roller shutter motors and indoor tube shutter motors. What. It incorporates a 433 MHz RollingCode receiver with a capacity of 30 codes.

Save with this discounts

Quantity Unit discount You Save
3 3% €3.51
5 5% €9.75
10 10% €39.00


We ship your order within 24/72 hours



Secure payment: Card, Bank transfer, Bizum



Fast shipping from Spain Except bulky



MOTORLINE MC75

Electronic switchboard Motorline MC75 for indoor roller shutter motors and indoor tube shutter motors. What. It incorporates a 433 MHz RollingCode receiver with a capacity of 30 codes.

CHARACTERISTICS OF MOTORLINE MC75

  • Detection of stress by wave variation;
  • Capable of working with motors up to 1500W;
  • Work time ends when you reach the end of the race;
  • It allows control programming without having to go to the control room;
  • Outlet for courtesy light with command control;
  • Possibility of working with a single or double button holder;

TECHNICAL DATA MC75

  • FoodOther: 230Vac 50/60Hz
  • Power output for engine: 1500W
  • OP transmitters: 12 Bits or RollingCode
  • Maximum memory capacity: 30 codes
  • Operating temperature20 °C to 55 °C
  • Radio receiver incorporated: 433.92 MHz
  • Output for auxiliary fittingsFor the purposes of this Regulation:
  • Output for external lamp: 500W
  • Fuse engine inputThe following: 5x20mm 8Ah
  • Low voltage fuse for accessory outputThe following: 5x20mm 65mA

MANUAL MC75

Instruction manual Motorline MC75

Type of frame
Roller motor box
