Sommer SSR-3-St

Sensor 3 in Dual technology for standard automatic doors and emergency exit.

Activation outputs available: current, frequency or relay.

According to the EN16005 standard.

Microwave technology + active infrared.

Three applications in a single sensor

Sensor 3 in 1 safety and activation of standard doors (relay) or emergency pathways (current / frequency).

Installation equipment only need a sensor for all types of sliding doors.

It requires only 30 mm vertical space for internal mounting inside door motor covers or false ceilings with the internal mounting bracket HA-130.

Pedestrian

The door learning technology provides unparalleled security for pedestrians.

3-row infrared safety curtain protects pedestrians in the door closing area and around it.

Supervised security system.

Energy efficiency

Unidirectional detection technology reduces energy losses in buildings by up to 20%.

The filtration of cross traffic reduces the unintentional activations of the door caused by the pedestrians that transit in parallel to it.

Less time at the point where it is installed

Installation instructions clearly printed on the sensor body.

Factory-configured DIP switch settings in accordance with EN16005 standard.

The smart software prevents false activations of the doors.

The sensor's body is one-piece, which prevents pieces from being lost or broken during installation.
