Motor kit EMFA 800N and 1.000N MTCH for residential sectional doors
KIT MTCH 800-1000
€195.00
VAT excluded
235,95 €
Tax incl.
Product discontinued by the manufacturer. Not available for sale.
This model has been officially replaced by a more current version, which incorporates technical and functional improvements.
👉 Recommended substitute product:
Motor kit EMFA MTCH NEW WIFI 800N and 1000N for sectional doors
We ship your order within 24/72 hours
Secure payment: Card, Bank transfer, Bizum
Fast shipping from Spain Except bulky
Motor kit EMFA 800n and 1.000n MTCHFor sectional doors of residential intensive use with strap Guide at 3350mm or 4350mm.
Features
- MTCH 800 for doors up to 10 m².
- MTCH 1000 for doors up to 15 m².
- Start and soft stop.
- Minimizes the engine effort on the door.
- Self-learning control of strength both in opening and closing.
- Closing over-effort causes automatic investment of more than 150mm.
- Low voltage protection, the system will not perform any opening or closing action, to protect the control panel.
- Transmitter system, to avoid matching codes or pirates.
- Safety block.
- Automatic closure.
| MTCH 800 | MTCH 1000 | |
| Motor feed | 230V, 50HZ / 120V, 60Hz | 230V, 50HZ / 120V, 60Hz |
| Motor tension | 24 VDC | 24 VDC |
| Lighting light bulb | 25W / 230V | 25W / 230V |
| Protection class | IP 20 | IP 20 |
| Operating temperature | -30 +60 ºC | -30 +60 ºC |
| Speed ≈ | 12 cm / s | 12 cm / s |
| Frequency | 433.92 MHz | 433.92 MHz |
| Traction force | 800 n | 1000 N |
| No. Max. demonstration | 20 | 20 |
| Transmission | Strap | Strap |
| Time Close Auto. adjustable | 0 ÷ 100 sec | 0 ÷ 100 sec |
| Courtesy light time | 3 min. | 3 min. |
| Max. lifting height | 2.5 m. | 3.3 m. |
| Door width | ≈4 m. | 4.5 m. |
| Max. m² door | 10 m². | 15 m². |
| Guide | 3 and 4 m. | 3 and 4 m. |
Models available
•MTCH 800/3350 (204045): 800N engine with a 3350mm strap guide (2x1,675m) + 2 emitters + wall button.
• MTCH 800/4350 (204046): 800N engine with 4350mm strap guide (2x16.75m + 1,000m) + 2 emitters + wall button.
• MTCH 1000/3350 (204047): 1.000N engine with a 3350mm strap guide (2x1,675m) + 2 emitters + wall button.
• MTCH 1000/4350 (204048): 1.000n engine with a 4350mm strap guide (2x16.75m + 1,000m) + 2 emitters + wall button.
MANUAL
- Maximum door area (m2)
- from 10m² to 13m²
from 14m² to 17m²
