Motorline GALO
Motor for sliding doors Motorline GALO
Motor sliding Motorline GALO Brushless
Automation Motorline GALO Brushless
Sliding Motor Brushless Motorline Gallo 36V to...
Motorline GALO
Motor for sliding doors Motorline GALO
Motor sliding Motorline GALO Brushless
Automation Motorline GALO Brushless
Sliding Motor Brushless Motorline Gallo 36V to Motorize Super Intensive Use Doors

Sliding Motor Brushless Motorline Gallo 36V to Motorize Super Intensive Use Doors

GALO
€366.00
VAT excluded

442,86 €

Tax incl.

Brushless engine Motorline Gallo 36V, brushless, Super intensive use to motorize sliding doors that require access with high vehicle traffic.

High performance and speed 36VDC engine, for slide gate of up to 2200kg (4 Versions available).

The absence of brushes and the box Lubricated gears guarantee superintendent use With high performance.

Type of race finish
GALO



We ship your order within 24/72 hours



Secure payment: Card, Bank transfer, Bizum



Fast shipping from Spain Except bulky



Motorline GALO BRUSHLESS 36V for sliding gates

Brushless engine Motorline Gallo 36V, brushless, Super intensive use to motorize sliding doors that require access with high vehicle traffic.

High performance and speed 36VDC engine, for slide gate of up to 2200kg (4 Versions available)

The absence of brushes and the box lubricated gears guarantee superintendent use with high performance.

✓ Motorreductor Motorline Gallo 36Vdc with native encoder

✓ Super intensive use

✓ Obstacle detection

✓ Brushless brushless motor

✓ Integrated battery charger

Incomparable durability. Superior performance

The absence of brushes and the lubricated gearbox guarantee intensive use and high performance.

Innovative sliding structure that guarantees speeds of up to 18 m / min for gates up to 1200 kg

Technical characteristics Motorline GALO

Galo600 Gallo600 Speed Galo1200 Galo2200
Nominal current 7a 10a 10a 12a
Maximum absorbed current 12a 18a 18a 18a
Nominal power 260w 360w 360w 430w
Speed 120-240mm /'s 225-450mm /'s 150-300mm /'s 150-300mm /'s
Speed with the maximum weight supported 214mm /'s 400mm /'s 260mm /'s 260mm /'s
Impulse force 450n 450n 1000n 1400n
Maximum weight of the gate 600 kg 600 kg 1200 kg 2200 kg
Diameter of the pinion 72mm 84mm 84mm 84mm
Feed 230 VAC | 50/60 Hz
Motor feed 36 VDC
Food of the plant 21/26 VAC
Labor 55%
Noise ≤50db
Engine technology BLDC
Type of engine reduction Irreversible
Degree Ip44
Cycles / time Continuous service
Operating temperature -20 ° C at 55 ° C
Career end Magnetic / mechanical
Encoder Native digital encoder
Electronic Mc91bl-sc
Optional backup batteries Mbat26v2000

Electronic Center MC91BL-SC

Compatible with the MCONNECT Link device for management and control through the MCONNECT application

Why choose a brushless sliding engine?

Documentation

Manual Motorline GALO

Manual Motorline Mc91bl-sc

Maximum door weight
Between 500 and 650 kg
Between 900 and 1000 kg
Between 2000 and 3500 kg
