The receiver can memorize the transmitters Nice with the O-Code, FloR, TTS, Flo, and Smilo encodings.

Only transmitters belonging to the same coding family can be stored in the transmitter.

To find out if other transmitters have been previously memorized in the receiver and their membership encoding family, perform the following steps in order:

1. Cut off the receiver's power:
2. Power the receiver again and observe the number of flashes emitted by the LED;

• 1 blink = Flo encoding
• 2 blinks = O-Code / FloR / TTS encoding
• 3 blinks = Smilo encoding
• 5 flashes = no transmitters inserted.

There are two ways to memorize a transmitter on the receiver.

• Mode I: You can memorize all or a group of transmitter buttons on the receiver at once. The buttons are automatically associated with the preset commands in the control panel.
• Mode II: You can store only one button on the transmitter on the receiver and freely choose the function you want to associate it with.

To memorize the transmitter on the receiver by following step-step mode, or mode II, watch the video or run the following steps in order.

• Press the button on the OXI receiver once and check that its green LED starts flashing.
• Press and hold the transmitter button, which you want to associate with the receiver, until the LED on the receiver flashes three long times to confirm the memorization and then release it.
• Wait for the green LED on the receiver to stop flashing.

To cancel a transmitter from the receiver's memory, follow the procedure shown in the video or perform the following steps in order:

• Press and hold the receiver button.
• When the green LED remains solid on, continue to press the receiver button.
• At the same time, press and hold the transmitter button, which you want to cancel, until the LED on the receiver executes 5 quick flashes.
• Release both buttons.

To completely cancel the receiver's memory, follow the procedure shown in the video or perform the following steps in order:

• Press and hold the receiver button.
• Wait for your LED to light up in steady mode and, when it turns off, to flash 3 times. Release the receiver button just during the third flash.
• The LED starts flashing very quickly to end up with 5 slow flashes.

All transmitters associated with the receiver have been cancelled.

MANUAL

OXIBD Instruction Manual Nice
